IPC2128SB 8MP Deterrent IP Fixed Lens Bullet, 98FT IR, IP66, NDAA

More Views

IPC2128SB 8MP Deterrent IP Fixed Lens Bullet, 98FT IR, IP66, NDAA

Availability: In stock



Details

  •  IPC2128SB-ADF28KMC-I0IPC2128SB-ADF40KMC-I0
    Camera
    Sensor1/2.7", 8.0 megapixel, progressive scan, CMOS
    Lens2.8mm@F2.04.0mm@F2.0
    DORI DistanceLens (mm)Detect (m)Observe (m)Recognize (m)Identify (m)
    2.884.033.616.88.4
    4.0120.048.024.012.0
    Angle of View (H)112.4°86.5°
    Angle of View (V)60.1°44.1°
    Angle of View (O)146.1°112.5°
    Adjustment angle Pan: 0° ~ 360°Tilt: 0° ~ 90°Rotate: 0° ~ 360°
    ShutterAuto/Manual, 1 ~ 1/100000s
    Minimum IlluminationColour: 0.01Lux (F2.0, AGC ON)
    0Lux with IR on
    Digital noise reduction2D/3D DNR
    Day/NightIR-cut filter with auto switch (ICR)
    S/N>56dB
    IR RangeUp to 30m (98 ft) IR range
    Wavelength850nm
    IR On/Off ControlAuto/Manual
    DefogDigital Defog
    WDR120dB
    Video
    Video CompressionUltra 265, H.265, H.264, MJPEG
    H.264 code profileBaseline profile, Main profile, High profile
    Frame RateMain Stream: 8MP (3840*2160), Max 20fps; 5MP (3072*1728), Max 30fps; 4MP (2560*1440), Max 30fps; 1080P (1920*1080), Max 30fps;
    Sub Stream: 1080P (1920*1080), Max 30fps;720P (1280*720), Max 30fps; D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps;
    Third Stream: D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps;
    Video Bit Rate128 Kbps~16 Mbps
    OSDUp to 8 OSDs
    Privacy MaskUp to 4 areas
    ROIUp to 8 areas
    Motion DetectionUp to 4 areas
    White BalanceAuto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2
    Digital Noise Reduction2D/3D DNR
    Smart IRSupport
    FlipNormal/Vertical/Horizontal/180°/90°Clockwise/90°Anti-clockwise
    DewarpingSupported
    HLCSupported
    BLCSupported
    Audio
    Audio CompressionG.711
    Two-way audioSupported
    SuppressionSupported
    Sampling Rate8KHZ
    Storage
    Edge StorageMicro SD, up to 256GB
    Network StorageANR
    Network
    ProtocolsIPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS
    Compatible IntegrationONVIF (Profile S, Profile G, Profile T), API
    ClientEZStation
    EZView
    EZLive
    Web BrowserPlug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below
    Plug-in free live view: Chorme 57.0+, Firefox 58.0+, Edge 16+, Safari 11+
    Interface
    Network1 RJ45 10M/100M Base-TX Ethernet
    Built-in MicSupported
    Built-in SpeakerSupported
    Alarm LightSupported
    Certifications
    CertificationsCE: EN 60950-1
    UL: UL60950-1
    FCC: FCC Part 15
    General
    PowerDC 12V±25%, PoE (IEEE 802.3af)
    Power consumption: Max 10.5W
    Dimensions (L × W × H)191× 75 × 74mm (7.5” × 3.0” × 2.9”)
    Net Weight0.41kg (0.90lb)
    MaterialMetal
    Working Environment-30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing)
    Strorage Environment-30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing)
    Surge Protection2KV
    Ingress ProtectionIP67
    Reset ButtonSupported
  • Additional Information

    UPC No
    Camera Housing Bullet
    Camera Resolution 4K
    Camera Technology IP

    IPC2128SB 8MP Deterrent IP Fixed Lens Bullet, 98FT IR, IP66, NDAA

    USD

    $99.00
